Cisco C9200L-48P-4G-E Switch

Cisco C9200L-48P-4G-E Switch

C9200L-48P-4G-E is the Catalyst 9200L 48 ports full POE+ 4x1G uplink Switch, with Network Essentials software. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.

Cisco Catalyst 9200 Series Features:

  • Flexible downlink options with data or PoE+.
  • Up to 48 ports of full Power over Ethernet Plus (PoE+) capability.
  • UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure.
  • Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps.
c9200l-48p-4g-e
Product Specification
Model C9200L-48P-4G-E
Downlinks total 10/100/1000 or PoE+ copper ports 48 ports full POE+
Uplink configuration 4x 1G fixed uplinks
Default primary AC power supply PWR-C5-1KWAC
Fans Fixed redundant
Software Network Essentials
Stacking bandwidth 80 Gbps
DRAM 2 GB
Flash 4 GB
Switching capacity 104 Gbps
Forwarding rate 154.76 Mpps
Chassis Dimensions 1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm


Supported Products

Product number

Product description

C9200-STACK-KIT=

C9200 Stack Kit Spare

C9200L-STACK-KIT=

C9200L Stack Kit Spare

STACK-T4-50CM

50CM Type 3 Stacking Cable

STACK-T4-1M

1M Type 3 Stacking Cable

STACK-T4-3M

3M Type 3 Stacking Cable



Power Supplies

Product Number

Product Description

PWR-C5-1KWAC/2=

1000WAC power supply spare
